Cleaning
49
4.4 Assembly
Please observe the following during assembly!
When you mount the chain frame, make sure
x That is carefully attached at all three holding points.
x If necessary, turn the clutch hub (2) manually until the
coupling engages.
x When placing on the pressing roller swing it away from
the stop limit.
x Correct position 1
x Correct position 2
1
2
3
1
2
3
