Operation
18
Example:
+ + +
=
3.2.1.2 Long Fanning
The long fanning function is for placing the individual slices in rows parallel to the stop.
The number of rows can be set using the “X” button. Up to 4 rows are possible with the
standard program. When making preparations, it is recommended to set the slice counter
to “000”. The machine then fans multiple layers on top of each other.
If rows are to be generated on portioning units (foils, PE trays, foam trays, trays etc.), you
can enter the outer dimensions of the portioning units L x W for central placing. (Option
only HA 800: the machine then uses the calibre recognition option to calculate the best
placing point.)
Example:
+ + +
+ 3 x “X button”
= 4 stacks
Select
“Stacking”
function
=
3 x “X button”
= 4 rows
Select
“Long fanning”
function
