Cleaning
42
Guide rail:
x Swivel up the last slice clamp as preparation.
x Pull the guide rail to the carriage wall with your right
hand.
x Hold the guide rail as illustrated in the picture and lift
it until the guide piece jumps out of the guide.
x Remove the guide rail from the carriage.
Last slice clamp (spike plate):
x Swivel up the last slice clamp as preparation.
x Loosen the black knurled nut by a few turns.
x Pull the plate upwards and swing the lower holding
bolt out of the slot.
Taking off the carriage:
x The limit stop must be completely closed.
x The carriage must be pulled to the initial position.
x Fold down the last slice holder.
x Release the star grip.
x Pull out the carriage carefully upwards.
1
2
