Domain
Configure the destination server domain for XMPP protocol. This option
is not editable for SMTP.
User Name
Configure the authorization user name of the destination server.
Password
Configure the authorization user password for the destination server.
From
Configure the sender name for SMTP protocol. This option is not
editable for XMPP.
To
Configure the receiver’s address.
Extra Attribute Name
Configure extra attribute’s name reserved for protocol specific attributes
such as “jid” for XMPP protocol. If “jid” is specified, user name and
domain will be overridden.
Extra Attribute Value
Configure extra attribute’s value reserved for protocol specific attributes
such as “abc@gmail.com” for “jid” of XMPP protocol. If it’s specified,
user name and domain will be overridden.
Up to 10 destinations can be configured here. The P values are listed in below table.
Table 20: Action URL - Destination P-values
P Value
Destination
Value Format
P9910
Destination 1
String. Each P value consists of all the options configured for this
destination.
Example 1 - Destination 1 with protocol XMPP and 2 extra Attributes
configured:
P9910=serverName=destination1&protocol=XMPP&serverAddress=talk.
google.com&port=5222&user=username1&password=password1&from=
&to=to1&domain=gmail.com&extraAttrName1=extraAttrValue1&extraAttr
Name2=extraAttrValue2
Example 2 - Destination 2 with protocol SMTP and 3 extra Attributes
configured:
P9911=serverName=destination2&protocol=SMTP&serverAddress=smtp
s://smtp.gmail.com&port=465&user=username2&password=password2&
from=username2&to=to2&domain=&extraAttrName1=extraAttrValue1&e
xtraAttrName2=extraAttrValue2&extraAttrName3=extraAttrValue3
The highlighted strings in above examples are the actual values
configured in each field for the destination.
P9911
Destination 2
P9912
Destination 3
P9913
Destination 4
P9914
Destination 5
P9915
Destination 6
P9916
Destination 7
P9917
Destination 8
P9918
Destination 9
P9919
Destination 10
 Notification
After configuring destination server, users can configure notification information under phone’s web
UI->Settings->Outbound Notification->Notification. Click on “Add Notification” and users will see following
window to configure notification.
