FIRMWARE VERSION 1.0.0.14 GXP2200EXT USER MANUAL Page 20 of 26
Monitor the extension status as configured in UserID field.
• Call Transfer
Transfer the current active call to the extension configured in UserID
field.
• Call Intercom
Intercom/paging to the extension configured in UserID field.
• Speed Dial via Active Account
Similar to Speed Dial but it will dial based on the current active
account. For example, if the phone is
active, it will call the configured extension using account 2.
• Dial DTMF
Dial the DTMF digits filled in UserID field during the call.
• Eventlist BLF
Similar to the BLF option but in this mode the PBX collects the
information from the phones and sends it out in one single SIP
NOTIFY message. The PBX server has to support this feature.
When selected, eventlist URI needs t
o be filled out under web
GUI->Advanced Settings->MPK General Settings.
• Call Park
Enter the UserID as the call park/pickup extension provided from the
PBX server to park or pick up the call.
support this feature.
Account Select the SIP Account used for the multi-purpose keys.
Name Configure the display name for the multi-purpose key.
UserID Configure the UserID for the corresponding multi-purpose key mode.
MPK ID
This identifies the "MPK ID x" for "MPK x". The default number is from
1-160 for 160 MPKs in 4 GXP2200EXT boards.
For example, if MPK 1 's MPK ID is changed from 1 to 5, users will see
the configuration saved on MPK 5.
Event List URI
This field displays the configured eventlist URI for the account if
"Eventlist BLF" is used.
Note:
This field is for display ONLY.
The eventlist URI for each account can be
configured under web GUI->Advanced Settings->
Settings.
Display Format Configure the display format for the multi-purpose keys. Users could
select
display "Phonebook Name", "UserID", or "UserID(Phonebook
