Device Individual
Certificate
Device Individual Certificate of the device.
System Up Time System up time since the last reboot.
Table 19: Status/System Info
Account Page Definitions
GXV34x0 phones has 16 lines that can be configured to accommodate 16 independent SIP accounts. Each account has an
individual configuration page.
Account/SIP/General
Settings
Registration
Account
Active
Indicates whether the account is active. The default value for the first account is “Yes”.
Account Name Configures the name associated with each account to be displayed on the LCD.
SIP Server
Specifies the URL or IP address, and port of the SIP server. This should be provided by VoIP service
provider (ITSP).
SIP User ID
Configures user account information provided by your VoIP service provider (ITSP). It’s usually in the form
of digits similar to phone number or actually a phone number.
SIP
Authentication
ID
Configures the SIP service subscriber’s Authenticate ID used for authentication. It can be identical to or
different from the SIP User ID.
Authentication
Password
Configures the account password required for the phone to authenticate with the ITSP (SIP) server before
the account can be registered. After saving, it will appear as hidden for security purpose.
Name
Specifies the SIP server subscriber’s name (optional) that will be used for Caller ID display. The configured
content will be included in the From, Contact and P-Preferred-Identity headers of SIP INVITE message.
Tel URI
Indicates E.164 number in “From” header by adding “User=Phone” parameter or using “Tel:” in SIP packets,
if the phone has an assigned PSTN Number.
Disabled: Will use “SIP User ID” information in the Request-Line and “From” header.
User=Phone: “User=Phone” parameter will be attached to the Request-Line and “From” header in the
SIP request to indicate the E.164 number. If set to “Enable”.
Enabled: “Tel:” will be used instead of “sip:” in the SIP request.
Please consult your carrier before changing this parameter. Default is “Disabled”.
Voice Mail
Access
Number
Sets if the phone system allows users to access the voice messages by pressing the MESSAGE key on the
phone. This ID is usually the VM portal access number. For example, in UCM6xxx IPPBX, *97 could be used.
Network
Settings
Outbound
Proxy
Configures the IP address or the domain name of the primary outbound proxy, media gateway or session
border controller. It’s used by the phone for firewall or NAT penetration in different network environments.
If a symmetric NAT is detected, STUN will not work and only an outbound proxy can provide a solution
Outbound
Proxy
Sets IP address or domain name of the secondary outbound proxy, media gateway or session border
controller. The phone system will try to connect the Secondary outbound proxy only if the primary
outbound proxy fails.
