Grandstream Networks GXW4104 User Manual

Grandstream Networks, Inc. GXW410x User Manual Page 10 of 35
Firmware Version 1.3.4.13 Last Updated: 3/2012
FEATURES
GXW410x is a next generation IP voice and video gateway that features full interoperability with leading
IP-PBXs, SoftSwitches and SIP platforms. The Gateway series offers superb voice and video quality,
traditional telephony functionality, simple configuration, feature rich functionality and an additional video
port that enables the gateway to act like a video surveillance gateway.
SOFTWARE FEATURES OVERVIEW
 4 and 8 FXO port media gateways
 Video surveillance port (Available in HW revision 1 only)
 External power supply
 Two RJ-45 ports (switched or routed)
 TFTP and HTTP firmware upgrade support
 Multiple SIP accounts, multiple SIP profiles (choice of 3 profiles per account)
 Supports Audio Codecs: G711U/A, G723, G729A/B and GSM
 Supports Video Codecs: H.264
 G.168 – echo cancellation
 Flexible DTMF transmission: In Audio, RFC2833, SIP Info or any combination of the 3
 Selectable, multiple LBR coders per channel
 T.38 compliant
HARDWARE SPECIFICATION
TABLE 3: HARDWARE SPECIFICATION OF GXW410X
LAN interface
2xRJ45 10/100Mbps
LED
8 LEDs (GREEN)
Universal Switching
Power Adaptor
Input: 100-240V AC, 50/60Hz, 0.5A Max
Output: 12V DC, 1.25A
UL certified
Dimension
225mm (L) x 172mm (W) x 42mm (H)
Weight
0.29 lbs (3.5 oz)
Temperature
32~104°F
0~40°C
Humidity
10% - 90% (non-condensing)
Compliance
FCC, CE

Grandstream Networks GXW4104 Specifications

General

Brand	Grandstream Networks
Model	GXW4104
Category	Gateway
Language	English
