Grandstream Networks GXW4104 User Manual

Grandstream Networks, Inc. GXW410x User Manual Page 15 of 35
Firmware Version 1.3.4.13 Last Updated: 3/2012
T
ABLE 6: STATUS PAGE DEFINITIONS
Hardware Revision
Hardware version number: Main Board, Interface Board
MAC Address
The device ID in HEX format. This is a very important ID for ISP troubleshooting.
IP Address
This field shows WAN IP address of GXW410x
Product Model
This field contains the product model info (GXW4104 or GXW4108)
Software
V
ersion
Program: This is the main software release. Boot and Loader are not changed often.
System Up Time
This field shows system up time since the last reboot.
Registered
This field indicates whether the different SIP Accounts configured under Channels page
are successfully registered to the SIP server(s).
FXO Line Connected
This field will give the status of each physical FXO Line connected to the Gateway. It will
update the status regularly.
Yes - Connected and Idle
Busy - Connected and Busy
No - Not connected
Additionally it will also provide real time Caller ID information of Incoming as well as
Outgoing calls.
PPPoE Link Up
This field shows whether the PPPoE connection is running if connected to DSL modem.
Detected NAT Type
This field shows what kind NAT the GXW410x is connected to via its WAN port. It is
based on STUN protocol.
