Grandstream Networks, Inc. GXW410x User Manual Page 8 of 35
Firmware Version 1.3.4.13 Last Updated: 3/2012
B. FXS Gateway with GXW410x [No SIP Server required]
Alternatively, the GXW410x can be used without a SIP Server. You can use it in conjunction with a FXS
Gateway (Ex. GXW400x) and still be able to originate and terminate calls from IP to PSTN and vice
versa. All you need to make sure is that the 2 gateways are able to locate each other (they should be on
the same LAN or on Public IP addresses).
GXW400
X & GXW410X SCENARIO/TOLL- FREE CALLING BETWEEN LOCATIONS
In this diagram, configure the SIP Server field to be the IP Address of the other gateway (i.e. configure IP
address of FXS gateway to be SIP Server of GXW410x and vice versa). Please be sure you set SIP
Registration to No.
E
XPECTED CALL FLOW: Analog Phone (GXW400x) picks up and dials destination PSTN number. The call
gets routed to the GXW410x which dials out the digit string onto the FXO Lines, thus reaching the
destination PSTN endpoint. On the reverse, incoming calls from PSTN endpoints will be routed
automatically to the FXS Gateway through the GXW410x.
Branch A - Boston, MA
4 employees
Branch B – Denver, CO
4 employees
Internet
Cloud
GXW-400x
GXW-410x
Analog Phones
PSTN
Cloud
FX0
