P a g e | 25
GXW42xx User Manual
Version 1.0.15.30
Configuration Server IP
Address
Announces current Config Server Path IP address. Enter
12-digit new IP address.
Upgrade protocol for firmware and configuration update.
Enter “9” to toggle between TFTP and HTTP
Firmware version information.
Firmware upgrade mode. Enter “9” to rotate among the
following three options:
1. always check
2. check when pre/suffix changes
3. never upgrade
Enter the target IP address to make a direct IP call, after
dial tone. (See “Make a Direct IP Call”.)
Enter “9” to reboot the device; or
Enter MAC address to restore factory default setting
(See Restore Factory Default Setting section)
Phone calls between
different ports of the
same GW42xx
GXW42XX support inter-port calling from voice menu for
easy test/verification in factory
“700” Ring all ports and connect to first port pick up the call
“701-732” Call individual port
Automatically returns to Main Menu
Five Success Tips when using the Voice Prompt
1. “*” shifts down to the next menu option
2. “#” returns to the main menu
3. “9” functions as the ENTER key in many cases to confirm an option
4. All entered digit sequences have known lengths - 2 digits for menu option and 12 digits for IP
address. For IP address, add 0 before the digits if the digits are less than 3 (i.e. - 192.168.0.26
should be key in like 192168000026. No decimal is needed).
5. Key entry cannot be deleted but the phone may prompt error once it is detected
Placing a Phone Call
Phone or Extension Numbers
1. Dial the number directly and wait for 4 seconds (To change the default value, modify the following
setting - “No Key Entry Timeout”)
