Grandstream Networks HT502 - Advanced User Configuration; Table 10: Advanced settings

P a g e | 39
HT502 User Manual
Software Version
Program: This is the main software release. This number is always used for
firmware upgrade. Current release is 1.0.13.3 Boot and Loader are seldom
changed.
Bootloader: current version is 1.0.0.18.
Core: current version 1.0.13.1
Base: current version is 1.0.13.3
Extra: current version is 1.0.13.1
CPE: current version is 1.0.1.48
System Up Time
Shows system up time since the last reboot.
PPPoE Link Up
Indicates whether the PPPoE connection is up if the HT502 is connected to DSL
modem.
NAT
This filed indicates the type of NAT connection used by the HT502 via its WAN port.
Port Status
Displays relevant information regarding the each FXS port.
Port
Hook
Registration
DND
Forward
Busy
Forward
Delayed
Forward
FXS1
On Hook
Registered
Yes
613
FXS2
On Hook
Registered
No
614
• Both FXS port1 and FXS port2 are registered with this SIP Server.
• FXS Port 1 user has set Do Not Disturb.
• FXS Port 1 user has set his calls to be forwarded unconditionally to ext 613.
• FXS Port 2 user has set his calls to forward to 614 when his phone is busy.
