Grandstream Networks HT502 - Table 9: Status Page; Figure 3: Uplink;Downlink Bandwidth Limitation

P a g e | 38
HT502 User Manual
Figure 3: Uplink/Downlink bandwidth limitation
In addition to the Basic Settings configuration page, end users also have access to the Device Status page.
Table 9: Status page
MAC Address
The device ID, in HEX format. This is very important ID for ISP troubleshooting.
LAN and WAN Mac addresses will appear in this place. The LAN MAC address will
be used for provisioning and can be found on the label coming with original box
and on the label located on the bottom panel of the device.
WAN IP Address
This field shows WAN IP address of HT502.
Product Model
This field contains the product model info.
