Base IP Address for a LAN port. Default factory setting is 192.168.2.1.
Note: When the device detects WAN IP is conflicting with LAN IP, the LAN base
IP address will be changed based on the network mask -- the effective subnet will
be increased by 1. For example; 192.168.2.1 will be changed to 192.168.3.1 if net
mask is 255.255.255.0. Then the device will reboot
Default value is 100. The last segment of IP address assigned to the HT50x in the
LAN Network. Default configuration assigns IP address (to local network devices)
starting from 192.168.2.100.
Default value is 199. This parameter allows a user to limit the number of local
network devices connected to the internal router. Default configuration assigns IP
address (to devices connected to the LAN port) in a range from 192.168.2.100 up
to 192.168.2.199.
Sets the LAN subnet mask. Default value is 255.255.255.0
Base IP address for the LAN port, which functions as default gateway for its LAN.
Default value is 192.168.2.1
Default value is 120 hrs (5 days). The length of time the IP address is assigned
to the LAN clients. Value is set in units of hours.
This function forwards all WAN IP traffic to a specific IP address if no matching
port is used by HT502 or in the defined port forwarding.
Forwards a matching (TCP/UDP) port to a specific LAN IP address with a specific
(TCP/UDP) port.
