P a g e | 56
HT503 User Manual
Tone
Waiting information arrives. The CWCID information will still be displayed.
Disable Connected
Line ID
Default is No. If set to Yes, Connected Line ID will not be displayed even if
received..
Disable Reminder
Ring for On-Hold Call
Default is No. The reminder ring for the on-hold call will not be played when
this is set to Yes.
Disable Visual MWI
If set to “YES”, the MWI information will not be transferred to the analog
phone connected to the FXS port.
Do Not Escape '#'
as %23 in SIP URI
If set to “Yes”, device will use ‘#’ instead of %23 in the send URI.
Disable Multiple m line
in SDP
Default is No. If set to Yes, device will send only one m line in SDP, regardless
how many m field in the incoming SDP.
Ring Timeout
Sets the time in which an incoming call will stop ringing when not picked up.
Hunting Group Ring
Timeout
Default value is 20 seconds. In case this feature activated using * codes
(*92 code), the call will be forwarded after this preconfigured amount of
time.
No Key Entry Timeout
Default is 4 seconds.
Early Dial
Default is No. Use only if proxy supports 484 response. This parameter
controls whether the phone will send an early INVITE each time a key is
pressed when a user dials a number. If set to “Yes”, an INVITE is sent
using the dial-number collected thus far. Otherwise, no INVITE is sent until
the “(Re-) Dial” button is pressed or after about 5 seconds have elapsed.
The “Yes” option should be used ONLY if there is a SIP proxy configured
and the proxy server supports 484 Incomplete Address response.
Otherwise, the call will likely be rejected by the proxy (with a 404 Not Found
error).
Note: This feature is NOT designed to work with and should NOT be
