HT812/HT814 Administration Guide
Configures the HT812/HT814 to send a replicate of the SIP packets on the syslog.
Default is No
Download Device
Configuration
Downloads actual device configuration file in .txt format.
Download Device
XML Configuration
Downloads actual device configuration file in .xml format.
Allows users to upgrade the firmware with a single firmware file by browsing and
loading the file from computer (local directory).
Allows users to upload the configuration file by browsing and loading it from computer
(local directory).
Profiles Pages Definitions
Table 9: Profiles Pages
Activates / Deactivates the accounts. The FXS port configuration will not change if
disabled, although the port will not be operational, in this state, there will be no dial tone
when picking up the analog phone, and making/receiving calls will not be possible.
Configures SIP server IP address or domain name provided by VoIP service provider.
This is the primary SIP server used to send/receive SIP messages from/to HT812/HT814.
Specifies failover SIP server IP address or domain name provided by VoIP service
provider. This server will be used if the primary SIP server becomes unavailable.
Prefer Primary SIP
Server
Selects to prefer primary SIP server. The account will register to primary Server if
registration with Failover server expires. Default is No.
Specifies IP address or domain name of outbound Proxy, or media gateway, or session
border controller. Used by HT812/HT814 for firewall or NAT penetration in different
network environments. If symmetric NAT is detected, STUN will not work and only
outbound proxy can correct the problem.
Allow DHCP Option
120 (override SIP
Server)
Configures the HT812/HT814 to collect SIP server address from DHCP option 120.
Default is No.
Selects transport protocol for SIP packets; UDP or TCP or TLS. Please make sure your
SIP Server or network environment supports SIP over the selected transport method.
Default is UDP.
