Grandstream Networks HT818 User Manual

P a g e | 15
HT81x User Guide
Note: Check the package before installation. If you find anything missing, contact your system administrator.
HT81X Ports Description
The following figure describes the different ports on the back panel of the HT81X.
Table 3: Definition of the HT81X Connectors
Phone 1 & 2 (HT812)
Phone 1- 4 (HT814)
Phone 1- 8 (HT818)
Connects the analog phones / fax machines to the phone adapter using
an RJ-11 telephone cable.
WAN
Connects the phone adapter to your router, switch or modem using an
Ethernet RJ45 network cable.
co
LAN
Connects the phone adapter to your PC or switch using an Ethernet RJ45
network cable.
Figure 3: HT818 Package Contents
1x HT818
1x 12V Power Adapter
1x Ethernet Cable
1x Quick Installation Guide
1x GPL Statement
Figure 4: HT812 Back Panel
Figure 5: HT814 Back Panel
Figure 6: HT818 Back Panel
