P a g e | 17
HT81x User Guide
Figure 7: Connecting the HT81X
HT81X LEDs Pattern
There are four (4) LED types that help you manage the status of your HT81X.
Table 4: HT81X LEDs Pattern Description
LED Lights
Status
Power LED
The Power LED lights up when the HT81X are powered on and it flashes
when the HT81X is booting up
Figure 8: HT81X LEDs Pattern
