Grant QR Range User Manual

Page 35Appendix A: Digital Dual Thermostat
°C
!
Display screen
Temperature
display
Demand
indicator light
Warning triangle
indicator light
Indicator LED
Temperature
control dial
Cable glands
Screw
Reset button
(under temperature
control dial)
Yellow
Green
White
Brown
PL N
1
C
2
Permanent live
connection
Neutral
connection
Demand
terminal
Common
terminal
Satisfied
terminal
Temperature
probe wiring
harness
connection
Temperature
probe wiring
order
Figure A-1: Digital Dual Thermostat - Front View
Temperature control dial present
Figure A-2: Digital Dual Thermostat - Front View
Temperature control dial removed
Figure A-3: Digital Dual Thermostat - Rear View
Wiring cover and cable glands removed
