11
Oil Storage & Supply
System
Figure 3-3: De-aeration device system
Figure 3-2: Two pipe system
Filter
Fire
valve
Shut-off
valve
Shut-off valve
Shut-off
valve
See
Section 3.2
A
Return
Supply
Head A
(m)
Maximum pipe run (m)
0
0.5
1.0
1.5
2.0
3.0
3.5
10mm OD pipe
35
30
25
20
15
8
6
12mm OD pipe
100
100
100
90
70
30
20
Non
return
valve
Fire
valve
sensor
Sludge
valve
Fill
pipe
Vent
pipe
Level
gauge
Fuel
storage
tank
Fire
valve
Tankmaster
See
Section 3.2
Sludge
valve
Fill
pipe
Vent
pipe
Fuel
storage
tank
De-aeration device
e.g. Tiger Loop
See Figure 3-4
Fire
valve
sensor
Return
Supply
