12
3. Adjust the springs in the crush protection until the
distance is 37 +/-1 mm on both sides. Undo the lock nut
and adjust until the distance is correct. Tighten the nuts
again.
4. Adjust the crush protection switch.
a. Make sure that the switch is seated in the bottom
of the slits. Push down and tighten.
5. Check the safety switch adjustment. All checking of the
safety switch and crush protector switch has to be
performed with the roof on.
The error code 122 is issued in case the 16 mm gauge is
used. (Crush protection in action, hood goes up again.)
Check that no alarm is given and the hoods stay down
when the 8 mm gauge is used.
