ECO
Service manual
4. Programming
Flashloader 3.x )*
With this PC-program you can:
• Updgrade the software and language-file.
• Troubleshooting with the in- & output on the circuit board.
• Reset Granule- & Service time.
• Change date & time in the machine.
• Put in Service phone number.
Installation
The program can be supplied on a CD or by E-mail and is installed as follows:
1. Create and name a folder for the program on the hard disk. Use “Explorer” in the computer’s office
program.
2. Insert the CD and click the program file Flashloader 3.x.zip on the CD. Save the files in the folder
you have just created on your hard disk.
3. Tip: create a shortcut on the desktop to make it easier to find the program when you
need to start it
Cable Connection
Connect a serial RS-232 cable(straight) between the machine serial connector and a computer serial
port. If the computer does not have a serial port, what is known as a USB/serial adapter can be used.
For information on what is suitable for your particular computer, contact your IT specialist. The cable
is connected to the 9-pole contact at the detergent junction box for the machine. Check that the internal
cable is connected in the machine’s electrical cabinet to the J11 terminal on the control card. This cable
is then laid to the selected computer via the kitchen’s normal communication paths and connected to a
free COM port.
Use
1. Start the program by double-clicking the program file Flashloader 3.x.exe in the folder you created
on the hard disk or by clicking the icon you created on the desktop.
2. Select serialport, by click on Communication/Ports , and select the port to which the potwashing
machine is connected. (Flashloader remember this setting next time the Flashloader start.
3. Put the wash machine in stop mode by pressing STOP-button.
4. Press “Connect”.
5. For Troubleshooting
:
Press “Run from Flash”, and when the field “Outports” is white you can operate the machine
manually, and at the same time see what is happen to the inputs in the “InPorts” field.
The time, temperature settings, and tank-levels is displayed at the top.
