Graphic Whizard PT 335B Multi - Troubleshooting; Error Codes

To Previous Page

Troubleshooting

Error Codes

Code

Description

Remark

E-1

CR Motor Error

Home position sensor finds nothing after starting motor.

E-2

Elevator Error

Limit switch closed or sensor finds nothing when starting

motor after a period, or pulse from pulse sensor stops.

E-3

Elevator Error

Both table up sensor and lower sensor are triggered.

C-1

CR Cover Open

Safety cover is open.

C-2

Jam at Infeed

Infeed sensor is activated while machine is not running.

C-3

Jam at Outfeed

Outfeed sensor is activated while machine is not running.

C-4

No Paper or Paper Jam

Infeed sensor is not activated after machine starts for 12

seconds.

C-5

Please Set Paper

Press start but no paper.

C-6

Please Insert Tools

Press start but tools not installed.

C-7

Tray Level Err
