Graphic Whizard PT 335B Multi - Page 7

6
No.
Parts
Description
1
Slide-In Bar Lock
Crease/Perf bar entry lock
2
Slide-In Bar
Crease bar or perforation bar
3
Handle
Crease/Perf bar handle
4
Stand
Optional with casters
5
Power Socket
For system power
6
Power Switch
On/off
7
Feed Table Extension
To load longer sheets
8
Paper Stop
To hold the paper when it is feeding
9
Fixed Side Guide
For skew adjustment
10
Air Gate
Adjustable to control air flow
11
Front Guide
Let one sheet enter without double feeding
12
Skew Adjust Wheel
To change the angle of fixed side guide
13
Feed Table
To load sheets
14
Stack Height Sensor
Controls table height
15
Vacuum Feed System
Assists in feeding sheets
16
Front Guide Knob
To adjust the height of sheet separators on front guide
17
Blower Knob
To adjust the blower power
18
Paper Deflectors
Controls sheet in feeder
19
Control Panel
Display and input
20
Tray Guides
Adjustable guides to stack sheets on output
21
Exit Tray
Exit tray
22
Clip
Release to uninstall the shaft
23
Outfeed Shaft
To install the outfeed counter rollers
24
Linear Tool & Exit Tire Anvil
Works together with linear tools and exit wheels
25
Depth Adjust Screw
To adjust the depth or crease or perforate
26
Depth Adjust Screw
To adjust the depth of liner tools
27
Linear Tools
Roller, scorer, kiss cutter, slitter, or perforator
28
Mounting Bar
To install exit wheels and linear tools
