Graphy Tera Harz Cure - Basic Specification

7 / 25
3. Basic Specification
□ Tera Harz Cure
Properties
Description
Input Voltage
100-240VAC, 50/60Hz
Output Voltage
24V, 12.5A
Screen
7.9” TFT Touch LCD
Light Source
UV LED
LED Wavelength
405nm
LED power
200W
LED Energy Density(Max) (*)
280,000mJ/㎠
Irradiance of UV Light(Max) (*)
1,000mW/㎠
LED Warranty Time
1,000h
Operation Temperature
5-35°C
Curing Space
MAX. Ø180 x 65mm
Curing Time (Setting range)
1-60 min / 5-55 sec
Dimension
275 x 310 x 300mm
Weight
Unit : 8.7Kg, Box : 1.3Kg
(*)The LED energy density is the accumulated measurement result for 5 minutes using the
standard UV Meter of Graphy..
□ Nitrogen Generator (when added)
Properties
Description
Nitrogen purity at the outlet (maximum)
95% or more
Nitrogen flow rate at the outlet
3.5~4L/min
Dimension
275 x 310 x 310mm
Weight
Unit : 3.2Kg, Box : 0.3Kg
Power Source
Not needed
Air hose diameter
Ø6
Min. air pressure required at compressor
7Kgf/㎠ ≒ 7 bar ≒ 0.7Mpa or more
Min. air flowrate required at compressor
100L/Min or more
Min. air tank size required
10L or more
