March 16, 2006 K2 Media Client Version 3.0.1.19 Release Notes 13
RS-422 connections
RS-422 connections
When using automation software to control the K2 Media Client via the RS-422 ports,
take care as you make your connections and configure your automation software.
Some remote control protocols, such as VDCP, have a “Select Channel” command
that is designed to control any channel via any RS-422 connector. The K2 Media
Client does not support this type of protocol command, as each RS-422 connector is
hard-coded to a single specific channel. Therefore, to control a given K2 Media Client
channel, use only that channel’s specific RS-422 rear panel connector.
To verify correct connection and configuration of automation software, do the
following:
1. Connect to only one RS-422 rear panel connector on the K2 Media Client.
2. Test the automation software and verify that it is correctly controlling the one
channel associated with that RS-422 rear panel connector.
3. Connect to each RS-422 rear panel connector in turn, and test the automation
software similarly for each connection. Verify correct operation of each connection
and its associated one channel before making multiple connections.
The following sections provide the information you need to identify and verify the K2
Media Client channel associated with each RS-422 rear panel connector.
RS-422 ports and channels on K2 Media Client models
The table below and the following diagrams describe how the RS-422 rear panel
connectors map to the channels of the different K2 Media Client models.
RS-422 Rear Panel Ports
Model Description
Port 1 Port 2 Port 3 Port 4
HD-22 HD/SD model with two recorder channels, two player channels R1 P1 R2 P2
HD-13 HD/SD model with one recorder channel, three player channels R1 P1 P2 P3
HD-12 HD/SD model with one recorder channel, two player channels R1 P1 P2 --
HD-04 HD/SD model with no recorder channel, four player channels P1 P2 P3 P4
HD-03 HD/SD model with no recorder channel, three player channels P1 P2 P3 --
HD-02 HD/SD model with no recorder channel, two player channels P1 P2 -- --
SD-04 SD K2 Media Client C1 C2 C3 C4
