5
SPECIFICATIONS
723T 727T
6
Engine Kohler Command, two cylinder, Kohler Command, two cylinder,
4 cycle, air cooled 4 cycle, air cooled
Model No. CH23 CH740
Horsepower (G.I.H.P.) 23 (17.2 kw) 27 (20.2 kw)
Displacement 41 cu. in. (674 cc) 44 cu. in. (725cc)
No-load r.p.m. 3600 3600
Charging System 12VDC 15 amp. negative ground 12VDC 15 amp. negative ground
Starter Electric Electric
Electrical System Safety interlocked Safety interlocked
PTO 3100 r.p.m. (max) 3100 r.p.m. (max)
Electric clutch Electric clutch
Drive System Tandem hydrostatic T
6
hydrostatic transmission
transmission direct drive direct drive
Steering Dual levers independently control speed and direction of travel.
Zero turning radius (center of machine is pivot point)
Speed
Forward (variable) 0 to 9 mph (14.5 km/h) 0 to 10 mph (16.1 km/h)
Reverse (variable) 0 to 6 mph (9.6 km/h) 0 to 6 mph (9.6 km/h)
Fuel Tank Capacity 4.3 U.S. gal. (16.3 l) 8.0 U.S. gal. (30.2 l)
Tire Sizes
Front Drive Wheels
Standard 22 x 11 x 10 - 4 ply rated
Optional 22 x 10 x 10 - 4 ply rated
Tail Wheel 13 x 6.50 x 6 rib - 4 ply rated
Dimensions of Tractor
Seat Back Height 46" (1.17 m)
Seat Cushion Height 30.5" (.78 m)
Tractor Width 50" (1.26 m)
Tractor Length 79.5" (2.02 m)
Wheel Base 51.5" (1.31 m)
Weight - Uncrated 850 lbs (385.6 kg) 875 lbs (396.9 kg)
Weight - Crated 1020 lbs (462.7 kg) 1060 lbs (480.8 kg)
Hour Meter Standard
Rev. 01-08
