WHEEL LIFT ASSEMBLY - 52 " & 61" models
Item Order Description
No. No.
Item Order Description
No. No.
1 9
1 7
1
1 8
1 8
6
1 9 1 9
1 6
1 9
1 5
1 2
1 2
1 1
1 0
0 0 0 0 9
1 3
9
1 4
8
1 7
2
3
7
5
4
3
1 643500 Lift Channel - Upper Rt.
643501 Lift Channel - Upper Lt.
2 824982 Fork Mount
3 122522 Bearing - Tapered
4 257091 Washer .75 x 14 Ga.
5 253992 Lock Nut .75-16
6 481432 Dust Cap
7 282615 Spacer
8 125855 Seal
9 644221 Fork - Tapered Bearing
10 603970 Wheel & Tire Smooth Tread
9 x 3.5 x 4 Flat Proof
with Bearing & Spacer
11 902428 Wheel Bearing Spacer
12 120048 Bearing
13 247715 Carriage Bolt .625-11 x 5.5
14 253970 Lock Nut .625-11
15 822312 Stabilizer - Deck Lift
16 424052 Rubber Bumper
17 243609 Bolt .5-13 x 3.312 Grade 5
18 243614 Bolt .5-13 x 3.562 Grade 5
19 253930 Lock Nut .5-13
00009
