33 / 36
S1033_jh_V1_de
Update through USB port
Download the actual software package from the Internet, and
unpack it on your computer. Connect your switched off trans-
mitter with your PC, by using the included USB cable, which is
supplied with the package content, plug USB cable directly to
the micro USB port of the transmitter and the other end to a free
port in your computer. All other information can be found in the
instructions that come in the software package.
Problems during firmware update
Problem: POWER switch without function
If a firmware update for the transmitter is unsuccessful or the
transmitter program freezes and the transmitter cannot be
turned off using the "POWER" switch, then remove the transmit-
ter's battery after setting the switch to "POWER = OFF" position,
or pull the plug from the transmitter battery, reconnect it after
few seconds and leave the transmitter switched OFF.
Download the actual update file from internet and save it in the
"RECOVERY" folder in your SD card. The change the file name
in "R280.bin".
Insert the SD card in the transmitter.
Push and hold the Ctl 5 and Ctl 6 buttons at the same time to
the top and push the POWER button.
Now push and hold to the lower side within 2 - 3 seconds the
Ctl 5 and Ctl 6 for about 10 seconds.
Wait then at least 30 seconds. In the display will be shown no
image. During the update the transmitter cannot be switched
on.
After 30 seconds the transmitter switches on.
Declaration of conformity
33028 mc-28 HoTT
Graupner/SJ declares that the product is conform to EU norms.
EMV 2004/108/EC:
EN 301 489-1 V1.9.2
EN 301 489-17 V2.1.1
EN 62479:2010
LVD 2006/95/EC:
EN 60950-1 + A11 + A1 + A12 + A2:2013
R&TTE 1999/5/EC:
EN 300 328 V1.8.1
EN 62311:2008
