GRAUPNER MZ-10 HOTT Operating Instructions

1-2. Failsafe mode
- FAILSAFE
Move the control sticks on the transmitter to the desired preset failsafe positions. Press & hold
the MODE button for over 2 sec and release the button. The Graupner/SJ logo turns solid red,
indicating the failsafe mode has been set. Conrm the failsafe setting is correct by turning off
the transmitter. The throttle should go to the preset position.
- HOLD
Enter hold mode by pressing MODE button once from the failsafe mode. The Graupner/SJ
logo repeats to blink twice red with twice beep. Press & hold the MODE button for over 2 sec
and release the button. The Graupner/SJ logo turns solid red, indicating the hold mode has
been set. If you lose connection, all channels hold the last given command.
- OFF
Enter off mode by pressing MODE button once from the hold mode. The Graupner/SJ logo
repeats to blink 3 times red with 3 times beep. Press & hold the MODE button for over 2 sec
and release the button. The Graupner/SJ logo turns solid red, indicating the off mode has
been set. Even if you lose connection, the failsafe is not working.
- STANDARD
Enter standard mode by pressing MODE button once from the hold mode. The Graupner/SJ
logo repeats to blink 4 times red with 4 times beep. Press & hold the MODE button for over
2 sec and release the button. The Graupner/SJ logo turns solid red, indicating the standard
mode has been set. standard features that the throttle channel ( channel Number 1 ) is move
into low throttle position and other channels hold last given command.
The mz-10 has the trainer function. The function activates when you select Teacher, Pupil
and Normal mode by RF TRAINER SWITCH.
1). Mode setting
1-1. Teacher setting
Move transmitter’s RF TRAINER SWITCH of the TEACHER transmitter to TEACHER
position. Press & hold the MODE button and switch on the transmitter. The Graupner/SJ
logo repeats to blink twice red with twice beeps, indicating that you set TEACHER Mode.
After two beeps sound twice, two beeps don’t sound. Now the mz-10 can bind and control
all channels of the pupil’s transmitter without restriction.
11. RF Trainer
Repeating that the Graupner/SJ logo blinks a single red with a single
beep
Repeating that the Graupner/SJ logo blinks twice red with twice beeps
Repeating that the Graupner/SJ logo blinks three times red with three
times beeps
Repeating that the Graupner/SJ logo blinks four times red with four
times beeps
STANDARD
OFF
HOLD
FAILSAFE
Mode
Button
Once
Once more
Once more
LED status and beep
NOTICE
Failsafe setting could be only set in case that RF TRAINER SWITCH
is at normal ight position
1-3. Normal setting
Getting back to the NORMAL mode from TEACHER or PUPIL mode, move transmitter’s RF
TRAINER SWITCH to NORMAL position. Press & hold the MODE button and switch on the
transmitter then the transmitter enters the failsafe mode automatically. The Graupner/SJ
logo repeats to blink a single red with a single beep. Turn off the transmitter then the NORMAL
setting is completed.
1-2. Pupil setting
When using the mz-10 as the pupil transmitter, bind the receiver at the NORMAL mode rst.
Turn off the transmitter, and still the receiver is turned on, and move transmitter’s RF TRAIN-
ER SWITCH to PUPIL position. Press & hold the MODE button and switch on the transmitter.
The Graupner/SJ logo repeats to blink a single red with a single beep, indicating that you
set PUPIL Mode. After one beep sound twice, a beep doesn’t sound. Now the Teacher’s
transmitter can bind and control all channels of the mz-10 without restriction.
11

GRAUPNER MZ-10 HOTT Specifications

General

Modulation	FHSS
Proper use	Airplane, Aircraft
Product type	Remote control
Product color	Black
Antenna length	120 mm
Frequency band	2.4 - 2.4835 GHz
Menu languages	German
Channels quantity	5 channels
Brand compatibility	Any brand
Number of memory records	1
Maximum operating distance	4000 m
Manual	Yes
Operating temperature (T-T)	-10 - 55 °C
Battery type	AA
Number of batteries supported	4
Built-in display	No

Weight and Dimensions

Depth	184 mm
Width	259 mm
Height	96 mm
Weight	630 g
