GRAUPNER MZ-10 HOTT Operating Instructions

SUPPORT AND SERVICE
BEFORE USE
OPENHOBBY A/S CENTER
1. BOX CONTENTS
Thank you for purchasing mz-10 HoTT 2.4GHz Radio System. This system is extremely
versatile and may be used by beginners and pros alike. In order for you to make the best
use of your system and to y safely, please read this manual carefully. If you have any
difculties while using your system, please consult the manual, our online Frequently Asked
Questions (on the web pages referenced below), your hobby dealer, or the Graupner/
SJ Service Center. Due to unforeseen changes in production procedures, the information
contained in this manual is subject to change without notice.
Please contact your Graupner/SJ importer in your region of the world or visit
“www.openhobby.com” to assist you with any questions, problems or service needs.
Only when the product is faulty after normal operation within the warranty period, we will
repair the product for free based on our regulations. The repair will be paid for by the con-
sumer when the damage is due to use in improper ways or beyond the warranty period.
Refer the WARRANTY CARD in a Package.
Graupner/SJ USA (OPENHOBBY LLC)
Phone : +1 855-5-RCisHoTT (+1 855-572-4746)
E - mail : service@openhobby.com
3245 University Ave, Suite 1520, San Diego, CA 92104
Please feel free to contact “www.openhobbby.com” to get all information on product features,
specications, running events and the newest product line up.
• mz-10 HoTT Transmitter
• Manual
• Shunt connecter
• GR-12L 6 Channel Receiver
• Charger
• Battery
• Waranty Card
• Before Use
• Support and Service
- Customer support
- Internet sales site
- A/S regulation
- Warranty regulation
• Openhobby A/S Center
1. Box Contents
2. Safety Notes
3. Features
4. Specication
5. Transmitter Control Identication
6. Adjustble Stick Length
7. Adjustble Stick Testion
8. Mode exchange of throttle stick for Mode 1 and Mode 2
9. What is HoTT
• Operation
1. Battery Installation
2. Charging Batteries
3. Turn on the transmitter
4. Binding
5. Servo Reversing
6. Dual Rate
7. Delta Wing
8. 2 AILE
9. V-Tail
10. FailSafe
11. RF Trainer
12. Country setting
13. Stick setting
14. Range testing
• Error
• Smart Box
• Firmware Update
• Safety Approval
2P
2P
2P
2P
2P
2P
2P
3P
3P
3P
3P
4P
5P
5P
5~7P
8P
8P
8P
8P
8P
9P
9P
9P
10P
10P
10P
10~11P
11~12P
12P
12~13P
13P
13P
13P
14P
14~15P
2
• Customer support
• A/S regulation
• Internet sales site
• Warranty regulation
Contents

GRAUPNER MZ-10 HOTT Specifications

General

Modulation	FHSS
Proper use	Airplane, Aircraft
Product type	Remote control
Product color	Black
Antenna length	120 mm
Frequency band	2.4 - 2.4835 GHz
Menu languages	German
Channels quantity	5 channels
Brand compatibility	Any brand
Number of memory records	1
Maximum operating distance	4000 m
Manual	Yes
Operating temperature (T-T)	-10 - 55 °C
Battery type	AA
Number of batteries supported	4
Built-in display	No

Weight and Dimensions

Depth	184 mm
Width	259 mm
Height	96 mm
Weight	630 g
