3
NOTICE
2. SAFETY NOTES
3. FEATURES
All instructions, warranties and other collateral documents are subject to change at the sole
discretion of Graupner/SJ. For up-to-date product literature, visit
http://www.openhobby.com and click on the support tab for this product.
This is a sophisticated hobby product and NOT a toy. It must be operated with caution
and common sense and requires some basic mechanical ability. Failure to operate this
product in a safe and responsible manner could result in injury or damage to the product or
other property. This product is not intended for use by children without direct adult supervi-
sion. Do not attempt disassembly, use with incompatible components or augment product in
any way without the approval of Graupner/SJ. This manual contains instructions for safety,
operation and maintenance. It is essential to read and follow all the instructions and warn-
ings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
1. 5 channels radio control set with Graupner/SJ HoTT 2.4 GHz technology(Hopping Intellective
Telemetry)
2. The use of up to 75 channels ensures extreme operating reliability and immunity to
external interference.
3. Real-Time Telemetry analysis.
4. Displaying Telemetry data and programming receiver outputs with the optional
Graupner/SJ Smart-Box and the optional sensors.
5. Future-proof update capability using data interface.
6. Advanced HoTT wireless trainer system makes Teacher and Pupil system more enjoy-
able and gives user convenience for the teaching/learning.
7. Simple, ultra-fast binding of transmitter and receiver.
8. Extremely fast re-binding, even at maximum range.
WARNING
Read the ENTIRE instruction manual to become familiar with the features of
the product before operating. Failure to operate the product correctly can
result in damage to the product, personal property and cause serious injury.
4. SPECIFICATION
Frequency band
Modulation
Output power
Current drain
Operating voltage
2.4~2.4835GHz
FHSS
100mW
Approx 125mA
3.4V~6V
2.4~2.4835GHz
FHSS
Approx 70mA
3.6V~8.4V
Transmitter mz-10
Receiver GR-12L
This is a sophisticated hobby product and NOT a toy. It must be operated with caution and
common sense and requires some basic mechanical ability. Failure to operate this product
in a safe and responsible manner could result in injury or damage to the product or other
property. This product is not intended for use by children without direct adult supervision. Do
not attempt disassembly, use with incompatible components or augment product in any way
without the approval of Graupner/SJ. This manual contains instructions for safety, operation
and maintenance. It is essential to read and follow all the instructions and warnings in the
manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or
serious injury.
1. Do not y your model near spectators, parking areas or any other area that could result in
injury to people or damage of property.
2. The radio system is affected by signal environment and the electronic jamming signals
can cause disorientation and loss of control of your aircraft.
3. Since models are hazardous when operated and maintained incorrectly, install and oper-
ate a radio control system correctly and always pilot a model so the model is kept under
control in all conditions
4. Ensure that all channels are working in the proper manner.
5. Do not y during adverse weather conditions. Poor visibility can cause disorientation and
loss of control of your aircraft. Strong winds can cause similar problems
6. When working with a model, always power on the transmitter rst and power off the
transmitter last.
7. After a model is bound to a transmitter and the model is set up in the transmitter, always
bind the model to the transmitter again to establish failsafe settings.
8. When working with a model, always power on the transmitter rst and power off the trans-
mitter last.
9. Ensure all batteries are full charged before ying.
10. Only to use the recommended adapter when charging the battery of the transmitter and
receiver
11.The transmitter shouldn’t be switched off at any time during ight
12. Perform a range check of the transmitter and the model before ying the model
13. Make sure all control surfaces correctly respond to transmitter controls before ying.
14. Perform the programming setup of the transmitter after removing a power battery from a
model or stopping an engine of a model.
15. Don’t move or touch the transmitter antenna during ight
