4
5. TRANSMITTER CONTROL IDENTIFICATION
Battery Cover
Data Pin
Charge Socket
RF Trainer Switch
Direction Button
Aileron Trim
Throttle Trim
Throttle and
Aileron Stick
Neck Strap Lug
Dual Rate Switch
Channel
Reverse LED
Wing Mix LED
Bind LED
5 Channel Switch
Rudder and
Elevator Stick
Elevator Trim
Rudder Trim
Power Switch
Mode Button
TX Handel
Antenna

Table of Contents

Other manuals for GRAUPNER MZ-10 HOTT

Preview: Manual
Manual48 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the GRAUPNER MZ-10 HOTT and is the answer not in the manual?

GRAUPNER MZ-10 HOTT Specifications

General IconGeneral
ModulationFHSS
Proper useAirplane, Aircraft
Product typeRemote control
Product colorBlack
Antenna length120 mm
Frequency band2.4 - 2.4835 GHz
Menu languagesGerman
Channels quantity5 channels
Brand compatibilityAny brand
Number of memory records1
Maximum operating distance4000 m
ManualYes
Operating temperature (T-T)-10 - 55 °C
Battery typeAA
Number of batteries supported4
Built-in displayNo
Weight and Dimensions IconWeight and Dimensions
Depth184 mm
Width259 mm
Height96 mm
Weight630 g
