GRAUPNER MZ-10 HOTT Operating Instructions

SAFETY APPROVAL
FIRMWARE UPDATE
For more information on the latest rmware and the related software, please refer to
the download menu on our website www.openhobby.com, www.graupner-sj.com
NOTICE: The optional USB adapter is needed to update.
Declaration of Conformity
(in accordance with ISO/IEC 17050-1)
- Product(s): Graupner/SJ mz-10 Transmitter,
Graupner/SJ GR-12L 6 Channel HoTT Receiver
Item Number(s):
Equipment class: 2
The objects of declaration described above are in conformity with the requirements of the speci-
cations listed below, following the provisions of the European R&TTE directive 1999/5/EC:
EN 62479:2010
EN 60950-1:2006/A11:2009/A1:2010/A12:2011
EN 301 489-1 V1.9.2
EN 301-489-17 V2.2.1
EN 300 328 V1.7.1
• FCC Information
Product(s) : Graupner /SJ mz-10 Transmitter
Contains FCC ID: SNL-36204210
FCC 47 CFR PART 15B
Product(s) :
Graupner/SJ GR-12L 6 Channel HoTT Receiver
FCC ID: SNL-16003510
FCC 47 CFR PART 15C
0678
• FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modications not expressly approved by the party responsible for compliance
could void the user‘s authority to operate the equipment.
• NOTE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
• FCC radiation exposure statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20
cm between the radiator and your body.
14

GRAUPNER MZ-10 HOTT Specifications

General

Modulation	FHSS
Proper use	Airplane, Aircraft
Product type	Remote control
Product color	Black
Antenna length	120 mm
Frequency band	2.4 - 2.4835 GHz
Menu languages	German
Channels quantity	5 channels
Brand compatibility	Any brand
Number of memory records	1
Maximum operating distance	4000 m
Manual	Yes
Operating temperature (T-T)	-10 - 55 °C
Battery type	AA
Number of batteries supported	4
Built-in display	No

Weight and Dimensions

Depth	184 mm
Width	259 mm
Height	96 mm
Weight	630 g
