U-Match Series DC
Inverter Service Manual
NO. Name of Part
GUHD48NK3FO
Product Code CF090W0720
Part Code Quantity
1 Front Grill '01575200001 2
2 Diversion Circle '10474100001 2
3 Cabinet '01514100002P 1
4 Handle '26235253 2
5 Front Side Plate '01314100021P 1
6 Axial Flow Fan '10434100003 2
7 Fan Motor '15704115 1
8 Motor Support Sub-Assy '01805200202 1
9 Chassis Sub-assy '01195200020P 1
10 Compressor Gasket '76710247 3
11 electrical heater '76518732 1
12 Drainage Joint '26113009 1
13 Electrical Heater '765100047 1
14 Valve Support Sub-Assy '01805200204P 1
15 Compressor '00204100001 1
16 Cut off Valve '07133844 1
17 Cut off Valve '07130209 1
18 Filter '07415210 1
19 Strainer '07210045 1
20 Valve Cover '26904100056 1
21 Rear Side Plate 01314100020P 1
22 Electronic Expansion Valve '07335283 1
23 Electric Expand Valve Fitting '4304001902 1
24 Strainer '07411100014 1
25 Temperature Sensor '3900028025G 1
26 Silencer '07245012 1
27 Pressure Protect Switch '46020003 1
28 Pressure Protect Switch '46020007 1
29 Gas-liquid Separator Sub-Assy '0722501801 1
30 4-way Valve '43000338 1
31 Magnet Coil '4300040032 1
32 Pressure Protect Switch '4602000902 1
33 Wire Clamp '02145008 1
34 Clapboard '0124520000701 1
35 Condenser Assy '01125200213 1
36 Rear Grill '01574100004 1
37 Coping '01264100008P 1
38 Electric Box Assy 01395200255 1
39 Main Board '30228000005 1
40 Filter Board '30228000006 1
41 Main Board '30224000035 1
42 Inductance '43120122 1
43 Terminal Board '42011242 1
44 Terminal Board '420101852 1
45 Supporting Strip '01894100010 1
46 Left Side Plate '01314100013P 1
47 Fan Motor '1570411501 1
To Next Page
