Gree GFH09K3FI

5
U-Match Series DC
Inverter Service Manual
QSPEVDU
3 PRODUCT DATA
3.1 Product Data of Indoor Unit
3.1.1 Duct Type
Model
Indoor unit GFH09K3FI GFH12K3FI GFH18K3FI GFH24K3FI
Product Code CF060N0420 CF060N0430 CF060N0440 CF060N0450
Outdoor unit GUHD09NK3FO GUHD12NK3FO GUHD18NK3FO GUHD24NK3FO
Product Code CF090W0630 CF090W0640 CF090W0650 CF090W0660
Capacity
Cooling Capacity kW 2.7(0.80-3.40) 3.5(0.90-3.70) 5.0(1.60-5.50) 7.0(2.20-8.50)
Heating Capacity kW 2.9(0.80-3.70) 3.8(0.90-4.10) 5.6(1.40-6.80) 8.0(2.40-9.50)
PdesignH kW 2.8 3.0 4.5 7.0
Power Input
Cooling kW 0.84(0.20-1.28) 1.17(0.20-1.40) 1.60(0.55-1.75) 2.18(0.85-2.50)
Heating kW 0.80(0.20-1.20) 1.05(0.22-1.20) 1.58(0.50-1.90) 2.21(0.80-2.75)
Design load Average
SEER / SCOP W/W 5.1/3.8 5.1/3.8 5.1/3.8 5.1/3.8
Energy Rate(Cooling / Heating) A/A A/A A/A A/A
Indoor Unit GFH09K3FI GFH12K3FI GFH18K3FI GFH24K3FI
Power Supply 220-240V~ 50Hz
Heat Exchange Cross Fin Coil Cross Fin Coil Cross Fin Coil Cross Fin Coil
Fan
Drive direct direct direct direct
Motor Output kW 0.04×1 0.05×1 0.07×1 0.11×1
Air Flow m
3
/h 650 750 1000 1400
Rated Ext. Static Pressure Pa 25 25 25 25
Ext. Static Pressure Range Pa 0~30 0~30 0~30 0~100
Sound Pressure Level(H/M/L) dB(A) 36/35/33/28 37/36/34/28 40/39/36/28 47/46/44/40
Air Filter Standard washable synthetic
Drain Piping mm ĭî ĭî ĭî ĭî
Outline Dimensions (W×H×D) mm 883×250×665 998×266×721 998×266×721 1239×268×558
Net Weight kg 26 33 33 34
Outdoor Unit GUHD09NK3FO GUHD12NK3FO GUHD18NK3FO GUHD24NK3FO
Power Supply 220-240V~ 50Hz
Heat Exchange Cross Fin Coil
Compressor
Type Rotary Rotary Rotary Rotary
Power Input W 942 942 1440 2550
Refrigerant
Control Electronic Expansion Valve
Charge kg 1.2 1.2 1.4 2.2
Outline Dimensions (W×H×D) mm 848×540×320 848×540×320 955×700×396 980×790×427
Net Weight kg 35 35 47 67
Piping Connections
Liquid Inch ĭ ĭ ĭ ĭ
Gas Inch ĭ ĭ ĭ ĭ
Max. Length m 20 20 20 30
Max. Height m 15 15 15 15
