GMV5 D.C INVERTER MULTI VRF SERVICE MANUAL
259
17
Throttle Assy
05374100006
1
18
Dry Filter Sub-Assy
07314100001
1
19
Gas Tube Filter
072190511
1
20
Dry Filter
07218769
1
21
Cut-off Valve 3/8
07334100011
1
22
Electronic Expansion Valve Coil
4304413206
1
23
Electronic Expansion Valve
07334390
1
24
Discharge Valve
07334100002
1
25
Electronic Expansion Valve Coil
4304413204
1
26
Plate-type Heat Exchanger
00904100005
1
27
Electronic Expansion Valve
07334412
1
28
One way Valve
04324001
1
29
Bidirectional Filter
07210044
1
30
Electronic Expansion Valve Sub-Assy
07334100030
1
31
Left Side Plate
01314712P
1
32
Chassis Sub-assy
01194100065P
1
33
Gas-liquid Separator
07424188
1
34
Base Frame Assy
01284711
1
35
Oil Separator
0742418601
1
36
Electrical Heater(Compressor)
7651873209
1
37
Compressor and Fittings
00204100011
1
38
Electric Heater(Compressor)
7651540713
1
39
Magnet Coil
4304410018901
1
40
Magnet Coil
4304410018904
1
41
Oil Equalizing Pipe Sub-Assy
04224100148
1
42
Oil Separator
07424100023
1
43
Pressure Switch
4602000911
1
44
Discharge Tube Sub-assy
04534100113
1
45
Front Panel
01544627P
1
46
Handle
26904100016
2
47
Front Panel
01544620P
1
48
Temperature Sensor Sub-Assy
39008000006G
1
49
Pressure Sensor
32218000009
1
50
Pressure Sensor
32218000008
1
51
Right Side Plate
01314713P
1
52
Cut-off Valve 7/8
07334100014
1
53
4-Way Valve Sub-Assy
04044100063
1
54
Filter
07218603
1
55
Magnet Coil
43044100189
1
56
4-way Valve
43000339
1
57
One way Valve
07335210
1
58
Nozzle for Adding Freon
06120012
2
59
Filter Board
30228000032
1
60
Rectifier
46018000014
1
61
Reactor
43138000049
1
62
Main Board
30228000031
1
63
Electric Box Assy
01394100431
1
64
Radiator
4901800000201
1
65
Main Board
30223000047
1
66
Radiator
49018000001
1
67
Terminal Board
42010247
1
