Gree GMV-120WM/B-F Service Manual

GMV5 D.C INVERTER MULTI VRF SERVICE MANUAL
261
15
Cut off Valve
07130239
1
16
Throttle Assy
05374100017
1
17
Electric Expansion Valve Sub-Assy
43044100162
1
18
Electric expand valve fitting
4304413203
1
19
Electronic Expansion Valve
07334390
1
20
Discharge Charge Valve
07334100002
1
21
One way Valve
04324001
1
22
Electric expand valve fitting
4304413204
1
23
Electronic Expansion Valve
07334412
1
24
Bidirection Strainer
07210044
1
25
Dry Filter Sub-Assy
00904100012
1
26
Dry Filter Sub-Assy
07414100016
1
27
Gas Tube Filter
072190511
1
28
Dry Filter
07218769
1
29
Gas-liquid Separator
07424138
1
30
Oil Separator
0742418601
1
31
Electric Heater(Compressor)
7651873209
1
32
Right Side Plate
01314713P
1
33
Chassis Sub-assy
01194100020P
1
34
Base Frame Assy
01284100002
1
35
Valve
07304100007
1
36
Cut off Valve
07334100011
1
37
Gas Hose Sub-Assy
04574100043
1
38
Cut off Valve
07334100014
1
39
Compressor
00204100011
1
40
Electric Heater(Compressor)
7651540713
1
41
Oil Equalizing Pipe Sub-Assy
04224100054
1
42
Magnet Coil
4304410018905
1
43
Oil Equalizing Pipe Sub-Assy
04224100440
1
44
Magnet Coil
4304410018901
1
45
Left Front Panel
01544100003P
1
46
Right Front Panel
01544100005P
1
47
Handle
26904100016
1
48
Front Top Cover
01264100004P
1
49
Sensor Sub-assy
39004100008G
1
50
Pressure Sensor
32218000009
1
51
Pressure Sensor
32218000008
1
52
Discharge Tube Sub-assy
04534100114
1
53
Oil Separator
07424100023
1
54
Pressure Protect Switch
4602000910
1
55
Left Side Plate
01314712P
1
56
4-Way Valve Sub-Assy
04044100055
1
57
Filter
07218603
1
58
Magnet Coil
4304410018903
1
59
4-way Valve
43000339
1
60
One way Valve
07335210
1
61
Nozzle for Adding Freon
06120012
1
62
Electric Box Assy
01394100447
1
63
Filter Board
30228000032
1
