Gree GMV-24WL/C-T Service Manual

GREE DC Inverter Side Discharge VRF Ⅱ for North America
137
Parts list
NO.
Name of Part
GMV-24WL/C-T(U)
GMV-28WL/C-T(U)
Product Code
CN850W0740
Product Code
CN850W0750
1
Compressor and
Fittings
'00900100019501
1
'00900100019501
1
2
Compressor Overload
Protector(External)
'00180030
1
'00180030
1
3
Compressor Overload
Protector(External)
'00183032
1
'00183032
1
4
Compressor Overload
Protector(External)
'00183031
1
'00183031
1
5
Compressor Gasket
'009012000004
3
'009012000004
3
6
Chassis Sub-assy
'017000000148P
1
'017000000148P
1
7
Chassis
'01284100101
1
'01284100101
1
8
Electrical Heater
'765100047
1
'765100047
1
9
Electric
Heater(Compressor)
'7651873215
1
'7651873215
1
10
Condenser Assy
'011002060314
1
'011002060314
1
11
Sensor Insert
'42020063
1
'42020063
1
12
Cable Cross Loop
'76510021
1
'76510021
1
13
Silencer
'07444105
1
'07444105
1
14
Pressure Protect
Switch
'46020006
1
'46020006
1
15
Strainer
'07415200002
1
'07415200002
1
16
Sensor Insert
'42020063
1
'42020063
1
17
Gas-liquid Separator
'07422809
1
'07422809
1
18
Nozzle for Adding
Freon
'06120012
1
'06120012
1
19
Temp Sensor Sleeving
'05212423
1
'05212423
1
20
Joint
'06652200001
1
'06652200001
1
21
fusible plug
'06332200001
1
'06332200001
1
22
Sensor Insert
'42020063
1
'42020063
1
23
Pressure Sensor
'322101002
1
'322101002
1
24
Plate-type Heat
Exchanger Assy
'00904100017
1
'00904100017
1
25
Nut with Washer
'70310012
2
'70310012
2
26
Plate-type Heat
Exchanger Assy
'007023000006
1
'007023000006
1
27
Electronic Expansion
Valve
'07334390
1
'07334390
1
28
Discharge Charge
Valve
'07133771
1
'07133771
1
29
Plate-type Heat
Exchanger
'00904100003
1
'00904100003
1
30
Temp Sensor Sleeving
'05212423
1
'05212423
1
31
Current Divider
'07223431
1
'07223431
1
32
Electronic Expansion
Valve
'07334447
1
'07334447
1
33
Sensor Insert
'42020063
1
'42020063
1
34
Electric Expand Valve
Fitting
'4304413205
1
'4304413205
1
35
Electric Expand Valve
Fitting
'4304413220
1
'4304413220
1
