Gree GMV-24WL/C-T Service Manual

GREE DC Inverter Side Discharge VRF Ⅱ for North America
138
NO.
Name of Part
GMV-24WL/C-T(U)
GMV-28WL/C-T(U)
Product Code
CN850W0740
Product Code
CN850W0750
36
Connection pipe
sub-assy
'05024100604
1
'05024100604
1
37
Nozzle for Adding
Freon
'06120014
1
'06120014
1
38
Pressure Sensor
'322101032
1
'322101032
1
39
Valve Support Assy
'01804100306
1
'01804100306
1
40
Cut-off valve
sub-assy(small valve)
'07334100042
1
'07334100042
1
41
Cut off Valve
'07130209
1
'07130209
1
42
Strainer
'07212001
1
'07212001
1
43
Cut-off valve
sub-assy(big valve)
'07334100044
1
'07334100044
1
44
Cut off Valve
'07334100016
1
'07334100016
1
45
Bidirection Strainer
'07210044
1
'07210044
1
46
4-Way Valve Assy
'030152000272
1
'030152000272
1
47
4-way Valve
'4300008201
1
'4300008201
1
48
Temp Sensor Sleeving
'05212423
3
'05212423
3
49
Sensor Insert
'42020063
3
'42020063
3
50
Magnet Coil
(electromagnetic valve)
'4304410018903
1
'4304410018903
1
51
Capillary sub-assy
'030006000255
1
'030006000255
1
52
Electromagnetic Valve
'43000054
1
'43000054
1
53
Magnet Coil
(electromagnetic valve)
'4304410018901
1
'4304410018901
1
54
Motor Support
Sub-Assy
'01804100309
1
'01804100309
1
55
Brushless DC Motor
'1570280000401
1
'1570280000401
1
56
Axial Flow Fan
'10434100005
1
'10434100005
1
57
Left Side Plate
'01314100043P
1
'01314100043P
1
58
Left Side Plate
'01314100043
1
'01314100043
1
59
Right Side Plate
Sub-Assy
'01314100109
1
'01314100109
1
60
Right Side Plate
'01314100046P
1
'01314100046P
1
61
Gland Bush
'26904100134
2
'26904100134
2
62
Wire conduit
'26904100132
2
'26904100132
2
63
Electric Box Assy
'100002062449
1
'100002062449
1
64
Bolt
'70210051
1
'70210051
1
65
Radiator
'430034000014
1
'430034000014
1
66
Main Board
'300027000235
1
'300027000235
1
67
Relay
'44020444
1
'44020444
1
68
Main Board
'300027000570
1
'300027000570
1
69
XY capacitor
'33020201
2
'33020201
2
70
Fuse
'46010055
1
'46010055
1
71
Terminal Board
'422000000015
1
'422000000015
1
72
Terminal Board
'422000060004
1
'422000060004
1
73
Insulation GasketC
'70410523
1
'70410523
1
74
Wire Clamp
'71010102
1
'71010102
1
75
Wire Clamp
'71010103
1
'71010103
1
76
Magnetic Ring
'49010118
3
'49010118
3
