Gree GMV-24WL/C-T Service Manual

GREE DC Inverter Side Discharge VRF Ⅱ for North America
139
NO.
Name of Part
GMV-24WL/C-T(U)
GMV-28WL/C-T(U)
Product Code
CN850W0740
Product Code
CN850W0750
77
Cable Cross Loop
'26900000008
1
'26900000008
1
78
Pass Wire Ring
Sub-assy
'76614102
1
'76614102
1
79
Cable Cross Loop
'76512008
1
'76512008
1
80
Filter Sub-Assy
'111001000086
1
'111001000086
1
81
Jumper
'4202021905
1
'4202021905
1
82
Electric Box Cover
'012077060106
1
'012077060106
1
83
Cabinet
'01514100007P
1
'01514100007P
1
84
Cabinet
'01514100007
1
'01514100007
1
85
Diversion Circle
'10474100003
1
'10474100003
1
86
Front Grill
'01572800003
1
'01572800003
1
87
Rear Side Plate
'01314100045P
1
'01314100045P
1
88
Handle
'26235253
1
'26235253
1
89
Front Side Plate
'01314100044P
1
'01314100044P
1
90
Front Side Plate
'01314100044
1
'01314100044
1
91
Handle
'26235253
1
'26235253
1
92
Coping
'01264100027P
1
'01264100027P
1
93
Rear Grill
'01574100010
1
'01574100010
1
94
Sensor Sub-assy
'39008000060G
1
'39008000060G
1
95
Temperature Sensor
Support
'26905202
1
'26905202
1
96
Heat Insulator
'12128748
13
'12128748
13
97
"Pipe Connection Nut
(""D"" shape) "
'06320004
2
'06320004
2
98
Corrugated Pipe
'05015408
1
'05015408
1
99
Drainage hole Cap
'06813401
3
'06813401
3
100
Drainage Joint
'06123401
1
'06123401
1
