Gree GMV-80WL/A-T

GREE DC Inverter Multi VRF System II Service Manual
67
Unit: mm
Model
A
B
C
D
E
GMV-80WL/A-T
GMV-100WL/A-T
GMV-121WL/A-T
GMV-80WL/C-T
GMV-100WL/C-T
GMV-121WL/C-T
980 360 790 650 395
GMV-141WL/C-T 940 460 820 610 486
3.7 Installation space requirement
If all sides of the ODU (including the top) are surrounded by walls, process according to the following
requirements for installation space:
