GREE Multi Variable Air Conditioners Indoor Unit
241
NO.
Model
GMV-ND30PHS/B-T(U) / GMV-ND36PHS/B-T(U) /
GMV-N42PHS/B-T(U)
Qty.
Product Code
CM810N0780/CM810N0740/CM810N0750
Part Name
Part Code
13
Left Side Plate Assy
01315200147
1
14
Hook
02112466
4
15
Water Level Switch
45020216
1
16
Water Pump
43138000058
1
17
Seal Plate
01495200078
1
18
Reactor
43138000047
1
19
Terminal board
4201115402
1
20
Terminal Board
4201800002601
1
21
Main Board
300002000009
1
22
Electric Box Assy
100002000984
1
23
Air Outlet Frame Assy
01375200023
1
24
Evaporator Assy
011001000070
1
25
Electric Expand Valve
Fitting
4304413215
1
26
Strainer
0741410000601
1
27
Electronic Expansion
Valve
07334468
1
28
Strainer
07415210
1
29
Foam Sub-Assy
12505200021
1
30
Top Cover Board Assy
01264100105
1
31
Right Side Plate Assy
01315200148
1
32
Display Board
30296000040
1
33
Temperature Sensor
3900005910
1
34
Temperature Sensor
390000592
1
35
Temperature Sensor
390000454
1
36
Drain Hose Sub-Assy
05232050
1
37
Corrugated Pipe
05015408
1
Above data is subject to change without notice, please refer the SP in global service website.
