Gree GMV-ND18PLS/C-T - Product Introduction; Names of Key Components; Rated Working Condition; Preparations for Installation

Multi Variable Air Conditioners Duct Type Indoor Unit
3
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Install units according to national wiring codes.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
An all-pole disconnection device which has at least 3mm clearances in all poles, and disconnection must be
incorporated in the fixed wiring in accordance with the wiring rules.
Gree Electric Appliances, Inc. of Zhuhai will not assume responsibility for any personal injury or property loss caused
by improper installation, improper debugging, unnecessary repair or not following the instructions of this manual.
2 Product Introduction
2.1 Names of Key Components
Fig2.1
NO.
① ② ③ ④ ⑤ ⑥
Name Electric box water pump Air Outlet Hooker
Air-return
Opening
Drain Pipe
2.2 Rated Working Condition
—
Indoor Side Condition
Outdoor Side Condition
Dry Bulb Temp(°C)
Wet Bulb Temp(°C)
Dry Bulb Temp(°C)
Wet Bulb Temp(°C)
Rated Cooling 27 19 35 24
Rated Heating
20
15
7
6
3 Preparations for Installation
NOTICE:
Product graphics are only for reference. Please refer to actual products. Unspecified
measure unit is mm.
