220
DC Inverter Multi
VRF Service Manual
18 Magnet Coil 4304000416 1
19 Electromagnetic Valve 43000054 1
20 Gas-liquid Separator 07424138 1
21 Liquid by-pass valve sub-assy1 07334324 1
22 Exit Tube Sub-Assy of Accumulator 04324776 1
23 Connection Pipe 05024954 1
24 Magnet Coil 4304000409 1
25 Electromagnetic Valve 43000054
26 Electric expand valve tting 4300010815 1
27 Electronic Expansion Valve 07130364 1
28 Electric Expansion Valve Sub-Assy 07334244 1
29 Accumulator 07424150 1
30 Suction Tube of Accumulator 04324753 1
31 Chassis Sub-assy 01194132P 1
32 Base Frame Sub-Assy 01284707 1
33 Compressor and ttings 00204124 1
34 Compressor and ttings 00204116 1
35 One way Valve 04324001 1
36 One way Valve 07130118 4
37 Magnet Coil 4304000411 1
38 Strainer Sub-Assy 07414132 1
39 Electromagnetic Valve 43044107 1
40 Fixed Mount3 01804181 1
41 Cut-off Valve 07138800 1
42 Cut-off Valve 07138799 1
43 Capillary Sub-Assy 04104153 1
44 Cut-off Valve 07130366 1
45 Electromagnetic Valve 43000054 1
46 Magnet Coil 4304000430 1
47 Support Crossbeam Sub-Assy 01324228P 1
48 Support Longitudinal 01894304P 1
49 Middle vertical prop sub-assy 01854111P 1
50 Mounting Rack Sub-Assy2 01324173P 1
51 Electric Box Assy 01394892
1
52 Electric Box Assy 01394789 1
53 Electric Box Cover 01264624P 1
54 Front Panel 0154461401P 1
55 Handle 26235253 4
56 Front Panel Sub-Assy 01544615P 1
57 Front Cover Plate 01264705P 1
58 Electric Box Cover2 01264170P 1
59 Strainer A 07210022 1
60 Cut-off Valve 07130239 1
61 Strainer A 07210022 1
62 low-pressure measure Sub-Assy 07384101 1
63 Oil Separator 07424186 1
64 connection Pipe Sub-Assy3 05025181 1
65 connection Pipe Sub-Assy2 05025182 1
66 connection Pipe Sub-Assy1 05025183 1
