Gree GMV5 Series Service Manual

GMV5 D.C INVERTER MULTI VRF SERVICE MANUAL
13
Outdoor Units_Heat Pump
-
12Ton
14Ton
16Ton
Horse Power
HP
14
18
20
Model
-
GMV-144WM/B-F(U)
GMV-168WM/B-F(U)
GMV-192WM/B-F(U)
Module combination
-
GMV-72WM/B-F(U)+
GMV-72WM/B-F(U)
GMV-72WM/B-F(U)+
GMV-96WM/B-F(U)
GMV-96WM/B-F(U)+
GMV-96WM/B-F(U)
Code
-
-
-
Power Supply
-
208/230V 3~60Hz
208/230V 3~60Hz
208/230V 3~60Hz
Compressor
Type
-
Inverter scroll type
Inverter scroll type
Inverter scroll type
Number
N
1+1
1+1
1+1
Refrigeration Oil
Brand
-
FVC68D or FV-68H
FVC68D or FV-68H
FVC68D or FV-68H
Pipe Connection
Gas Pipe Size
mm
28.6
28.6
28.6
in.
1 1/8
1 1/8
1 1/8
Liquid Pipe Size
mm
12.7
15.9
15.9
in.
1/2
5/8
5/8
Oil Balance Pipe
Size
mm
9.52
9.52
9.52
in.
3/8
3/8
3/8
Dimensions
(width×depth×height
)
External
Dimension
mm
930×765×1605+
930×765×1605
930×765×1605+
1340×765×1605
1340×765×1605+
1340×765×1605
in.
36-3/5×30-1/8×63-1/5
+
36-3/5×30-1/8×63-1/5
36-3/5×30-1/8×63-1/5
+
52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+
52-3/4×30-1/8×63-1/5
Weight
Net Weight
kg
225+225
225+300
300+300
lbs.
496+496
496+661
661+661
Maximum qty of connected indoor units
unit
25
29
33
Outdoor Units_Heat Pump
-
18Ton
20Ton
22Ton
Horse Power
HP
22
24
26
Model
-
GMV-216WM/B-F(U)
GMV-240WM/B-F(U)
GMV-264WM/B-F(U)
Module combination
-
GMV-96WM/B-F(U)+
GMV-120WM/B-F(U)
GMV-120WM/B-F(U)+
GMV-120WM/B-F(U)
GMV-72WM/B-F(U)+
GMV-96WM/B-F(U)+
GMV-96WM/B-F(U)
Code
-
-
-
Power Supply
-
208/230V 3~60Hz
208/230V 3~60Hz
208/230V 3~60Hz
Compressor
Type
-
Inverter scroll type
Inverter scroll type
Inverter scroll type
Number
N
1+2
2+2
1+1+1
Refrigeration
Oil Brand
-
FVC68D or FV-68H
FVC68D or FV-68H
FVC68D or FV-68H
Pipe Connection
Gas Pipe
Size
mm
28.6
34.9
34.9
in.
1 1/8
1 3/8
1 3/8
Liquid Pipe
Size
mm
15.9
15.9
19.05
in.
5/8
5/8
3/4
Oil Balance
Pipe Size
mm
9.52
9.52
9.52
in.
3/8
3/8
3/8
Dimensions
(width×depth×height)
External
Dimension
mm
1340×765×1605+
1340×765×1605
1340×765×1605+
1340×765×1605
930×765×1605+
1340×765×1605+
1340×765×1605
in.
52-3/4×30-1/8×63-1/5+
52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5+
52-3/4×30-1/8×63-1/5
36-3/5×30-1/8×63-1/5+
52-3/4×30-1/8×63-1/5+
52-3/4×30-1/8×63-1/5
Weight
Net Weight
kg
300+360
360+360
225+300+300
lbs.
661+749
749+749
496+661+661
Maximum qty of connected indoor
units
unit
37
41
45
