Gree GMV5 Series Service Manual

GMV5 D.C INVERTER MULTI VRF SERVICE MANUAL
263
4
Motor for Axial Fan Assy
15404100056
2
5
Axial Flow Fan Blade
10434100002
1
6
Fan Motor
15704119
1
7
Gas By-pass Sub- Assy
04634100012
1
8
Magnet Coil
4304410018906
1
9
Filter
07415200002
1
10
Electromagnetic Valve
43000054
2
11
Cover Plate
01264100005P
1
12
Rear Grill
01574100001
1
13
Condenser Assy
0112410009001
1
14
Low Pressure Survey Valve Sub-Assy
07334100010
1
15
Cut-off Valve 1/4
07130239
1
16
Throttle Assy
05374100003
1
17
Electronic Expansion Valve Fittingss
43044100012
1
18
Electronic Expansion Valve Fittings
4304413204
1
19
Electronic Expansion Valve
07331139
1
20
Discharge Valve
07334100002
1
21
Electronic Expansion Valve Fittings
4304413203
1
22
Check Valve
04324001
1
23
Electronic Expansion Valve
07334412
1
24
Bidirectional Filter
07210044
1
25
Plate-type Heat Exchanger Sub-Assy
00904100007
1
26
Dry Filter Sub-Assy
07314100002
1
27
Gas Tube Filter
072190511
1
28
Dry Filter
07218769
1
29
Left Side Plate
01314712P
1
30
Gas-liquid Separator
07424138
1
31
Oil Separator
0742418601
1
32
Electrical Heater(Compressor)
7651873209
1
33
Chassis Sub-Assy
01194100001P
1
34
Base Frame Assy
01284100002
1
35
Cut-off Valve 1/2
07334100013
1
36
Liquid Valve Sub-Assy
07304100009
1
37
Cut-off Valve 3/8
07334100011
1
38
Valve
07304100007
1
39
Cut-off Valve 1-1/8
07334100014
1
40
Gas Valve Sub-Assy
07304100008
1
41
Oil Equalizing Pipe Sub-Assy 1
04224100054
1
42
Magnet Coil (electromagnetic valve)
4304410018905
1
43
Magnet Coil (electromagnetic valve)
4304410018901
1
44
Oil Equalizing Pipe Sub-Assy 2
04224100059
1
45
Compressor and Fittings
00204128
1
46
Electric Heater(Compressor)
7651540714
1
47
Compressor
00204100011
1
48
Electric Heater(Compressor)
7651540713
1
49
Front Panel (Left)
01544100003P
1
50
Front Panel (Right)
01544100005P
1
51
Handle
26904100016
2
52
Cover Plate
01264100004P
2
53
Sensor Sub-Assy
39008000028G
1
54
Pressure Sensor
32218000009
1
