GMV5 HR HEAT RECOVERY VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery Ton 12 14 16
Model - GMV-Q144WM/B-F(U) GMV-Q168WM/B-F(U) GMV-Q192WM/B-F(U)
Module combination -
GMV-Q72WM/B-F(U)+
GMV-Q72WM/B-F(U)
GMV-Q72WM/B-F(U)+
GMV-Q96WM/B-F(U)
GMV-Q96WM/B-F(U)+
GMV-Q96WM/B-F(U)
Dimensions
(width×
depth×
height)
External Dimension
mm
1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
in.
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
Packaging Dimension
mm
1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
in.
55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8
55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8
55-7/8×33-1/8×69-
7/8+55-7/8×33-1/8×69-
7/8
Weight
Net Weight
kg 302+302 302+310 310+310
lbs. 666+666 666+683 683+683
Gross Weight
kg 317+317 317+325 325+325
lbs. 699+699 699+716 716+716
Maximum qty of connected indoor
units
unit 23 29 33
Protection
Devices
High Pressure
Protection
High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/Low voltage protection,
Remark
① .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130
℉
;
Evaporating temp.45
℉
; Return gas temp.65
℉
; Liquid temp.115
℉
) at 60Hz.
② .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate
tank. When replacing the compressor or oil separate tank, only the corresponding required oil amount shall be
charged.
