Outdoor Units_Heat Recovery Ton 18 20 22
Model - GMV-Q216WM/B-F(U) GMV-Q240WM/B-F(U) GMV-Q264WM/B-F(U)
Module combination -
GMV-Q96WM/B-F(U)+
GMV-Q120WM/B-F(U)
GMV-Q120WM/
B-F(U)+
GMV-Q120WM/B-F(U)
GMV-Q72WM/B-F(U)+
GMV-Q96WM/B-F(U)+
GMV-Q96WM/B-F(U)
Performance
Nominal Cooling
Capacity
Btu/h
216000 240000 264000
kW 63.3 70.3 77.4
Rated Cooling
Capacity
Btu/h 201000 222000 247000
Nominal Heating
Capacity
Btu/h 243000 270000 297000
kW 71.2 79.1 87.1
Rated Heating
Capacity
Btu/h 226000 252000 275000
Cooling Power Input kW 7.30+9.58 9.58+9.58 5.45+7.30+7.30
Heating Power Input kW 7.85+10.42 10.42+10.42 5.80+7.85+7.85
Sound Pressure
Level
dB(A) - - -
Power Supply - 208/230V 3~ 60Hz
Compressor
Type - Inverter scroll type Inverter scroll type Inverter scroll type
Number N 1+2 2+2 1+1+1
Motor Output
①
kW - - -
Starting Method - Inverter Inverter Inverter
Operating Range - - - -
Refrigeration Oil
Brand
- FVC68D or FV-68H FVC68D or FV-68H FVC68D or FV-68H
Fan
Type×Quantity - Propeller×(2+2) Propeller×(2+2) Propeller×(2+2+2)
Motor output W 750×2+750×2 750×2+750×2 750×2+750×2+750×2
Starting method - Inverter Inverter Inverter
Air ow rate
m
3
/h 14000+14000 14000+14000 14000+14000+14000
cfm 8240+8240 8240+8240 8240+8240+8240
Max. external static
pressure
Pa 82 82 82
in.W.G 0.328 0.328 0.328
Ambient
temperature
range
Cooling
°C -5~52 -5~52 -5~52
℉
23~125.6 23~125.6 23~125.6
Heating
°C -20~24 -20~24 -20~24
℉
-4~75.2 -4~75.2 -4~75.2
Refrigerant
Refrigerant Type - R410A R410A R410A
Refrigerant Charge
Volume
kg 11.2+11.7 11.7+11.7 9.6+11.2+11.2
lbs. 24.69+25.79 25.79+25.79 21.16+24.69+24.69
Control - EXV EXV EXV
Pipe
Connection
Low pressure Gas
Pipe Size
mm 28.6 34.9 34.9
in. 1 1/8 1 3/8 1 3/8
high pressure gas
pipe
mm 28.6 28.6 28.6
in. 1 1/8 1 1/8 1 1/8
Liquid Pipe Size
mm 15.9 15.9 19.05
in. 5/8 5/8 3/4
