GMV5 HR HEAT RECOVERY VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 24 26
Model - GMV-Q288WM/B-U(U) GMV-Q312WM/B-U(U)
Module combination -
GMV-Q96WM/B-U(U)+
GMV-Q96WM/B-U(U)+
GMV-Q96WM/B-U(U)
GMV-Q96WM/B-U(U)+
GMV-Q96WM/B-U(U)+
GMV-Q120WM/B-U(U)
Dimensions
(width×
depth×
height)
External Dimension
mm
1340×765×1605
+1340×765×1605
+1340×765×1605
1340×765×1605
+1340×765×1605
+1340×765×1605
in.
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
+52-3/4×30-1/8×63-1/5
Packaging Dimension
mm
1420×840×1775
+1420×840×1775
+1420×840×1775
1420×840×1775
+1420×840×1775
+1420×840×1775
in.
55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
+55-7/8×33-1/8×69-7/8
Weight
Net Weight
kg 315+315+315 315+315+370
lbs. 694+694+694 684+684+816
Gross Weight
kg 330+330+330 330+330+385
lbs. 728+728+728 728+728+849
Maximum qty of connected indoor units unit 50 53
Protection
Devices
High Pressure
Protection
High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/Low voltage protection,
Remark
① .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130
℉
;
Evaporating temp.45
℉
; Return gas temp.65
℉
; Liquid temp.115
℉
) at 60Hz.
② .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate
tank. When replacing the compressor or oil separate tank, only the corresponding required oil amount shall
be charged.
