4 PRODUCT DATA
4.1 Product Data at Rated Condition
LSQWF__M/N-M Cooling
Only
65 80 130
LSQWRF__M/N-M
Models
Heat
Pump
65 80 130
kW 60 76 120
Cooling
Ton 17 22 34
kW 65 80 130
Nominal
Capacity
Heating
Ton 19 23 37
Cooling kW 22.6 28.7 45.3 Power
Input
Heating kW 21.7 26.7 43.3
Power Supply 400V-3N-50Hz
Running Control
Microcomputer Auto Control;
Running Status Display; Abnormal Status Alarm
Safeties
High-Low Pressure Protection; Discharge Temp Protection;
Motor Overload Protection; Anti-freeze Water Flow Protection;
Low Water Flow Protection; Phase Sequence Protection;
Compressor Overload Protection; Compressor Inset Protection;
Presure Differential Protection;
Compressor Type Hermetic Scroll Compressors
Refrigerant Type R407C
m
3
/h 10.3 13.1 20.6 Water
Flow
GPM 45.4 57.7 90.7
Pressure
Drop
kPa 10 15 17.5
Heat Exchanger Shell and Tube Evaporator
Max.
Pressure
MPa 1
Cooler
Water
In/Out Pipe
Diameter
mm DN65 DN65 DN80
Heat Exchanger Finned Coil Type Condenser
Condenser
Fan Motor
Power Input
kW 1.15×2 1.15×2 0.75×4
Width mm 2110/2190 2110/2190 2410/2490
Depth mm 1100/1180 1100/1180 1900/1980
Outline/
Package
Dimension
Height mm 2140/2140 2140/2140 2240/2240
Net Weights
（Heat Pump）
kg 940 1030 1670
Operation Weights kg 1034 1133 1837
